Lettuce
Lactuca sativa L.
Symptoms induced in controlled conditions (fumigation with ozone)cv. Cogollo de TudelaChorotic lesions produced by ozone exposure on lettuce cv. Cogollo de Tudela lesions join together appearing like a continuous chorosis (A). Sometimes bifacial necrosis are observed in small areas of old leaves (B)
cv. Romana del PratOzone symptoms on lettuce cv. Romana del Prat appears on the tip of the oldest leaves as a chlorotic stippling (B and D). It can be easily distinguished with comparing with healthy leaf (C). Ozone lesions join together and the tip of the leaf turn into chlorotic completely (A and B). Chronic exposures to ozone produces bronzing or reddish lesions (E).
cv. Iceberg El ToroLettuce cv. Iceberg El Toro shows slight small chlorotic stippling on the old leaves of the plant (A and B). Small necrosis spots can be observed occasionally (B).
